Brass Non Return Valve
Brass non-return valves (NRVs), are automatic, one-way valves constructed from brass, designed to prevent backflow in plumbing, water, and fuel systems. They use a, typically spring-loaded, internal disc to allow forward flow and automatically close when pressure reverses, ensuring system integrity and preventing, for instance, contamination or pump damage. They function automatically without human intervention, opening at low cracking pressures and sealing tightly against reverse flow.
Technical Data
| Features of Brass Non Return Valve : | » Screwed Female Ends to IS 554 » Permits flow in one direction and shuts automatically if the flow reverses » Swing Type » Suitable For Water » Material – Full brass forged body & EPDM Seal |
| Material : | » Free Cutting Brass IS 319 Type (I) or BS 249 Type (I) or High Grade » Any Special Brass Material Composition as per customers requirement |
| Threads : | » ISO Metric (MM Threads), BA, BSW (Inches), UNC, UNF » Any threads as per custom design |
| Pressure Rating : | » Standard Applications : 10–16 bar (145–232 PSI) » Medium Pressure: 20–25 bar (approx. 300 PSI) » High Pressure : 3,000–6,000 PSI |
| Length / Size : | » 1/2", 3/4", 1", 1-1/4", 1-1/2", 2" » Any size available as per customer requirement |
| Finish And Coating : | » Natural, Nickle Plated, Tin Plated or any coating as per customer specification. |
